| Display | 6.1” × 3.5” (156 mm × 90 mm) color TFT, touch sensing | 6.1” × 3.5” (156 mm × 90 mm) color TFT, touch sensing |
| Inputs (Mic/Line) | 12 total:
Four XLR/TRS combo
Four XLR
Two stereo 1/4" TRS | 20 total:
Four XLR/TRS combo
12 XLR
Two stereo 1/4" TRS |
| Input (Talkback) | N/A | One XLR |
| Outputs | Two main XLR line-level
Four aux XLR line-level
One stereo TRS (line-level or in-ear monitor, 16Ω min. impedance)
One stereo cue, TRS, (line or headphone, 16Ω min. impedance) | Two main XLR line-level
Six aux XLR line-level
Two stereo aux. TRS (line-level or in-ear monitor, 16Ω min. impedence)
One stereo monitor TRS (line-level or headphone, 16Ω min. impedance)
One stereo cue TRS, (line-level or headphone, 16Ω min. impedance) |
| Mic & Line Input Channel Processing (both models) | 4-band parametric EQ with high/low shelving option,
variable 24 db/octave HPF & LPF, gate, compressor |
| 2-Track (USB) & FX Return Processing (both models) | 2-band shelving EQ, variable 24 dB/octave HPF, gate, compressor |
| Output Channel Processing (both models) | Main outputs and auxes 1–6: 1/3 octave GEQ • Limiter • 4 full-frequency notch filters • Variable 18dB/oct Low-cut and High-cut filters Auxes 7/8 & 9/10 (TM-16 only): 4-band PEQ, Limiter • Additional variable 18dB/oct Low-cut and High-cut filters |
| Recording | 14 tracks, requires USB 3.0 HD • FAT32 format • minimum 7800 RPM | 22 tracks, requires USB 3.0 HD • FAT32 format • minimum 7800 RPM |
| Groups (both models) | 8 DCA groups (with mutes), 8 Mute groups, auxiliaries may be used as sub groups |
| Cue (both models) | Selectable AFL or PFL |
| Effects (both models) | 4 professional effects engines including reverb, echo, delay, chorus. 50 factory, 50 user presets
1 pitch correct (assignable to any mono input channel) |
| Scene and Preset Memory | Scenes: 130 user-defined scenes, including all mixer parameters may be stored internally or on FAT32 formatted USB Channel and FX Presets: 130 user-defined channel presets and 130 FX presets may be stored internally or on FAT32 formatted USB |
| External Control (both models) | iOS TouchMix app for iPad, iPad mini, iPad Air. Control via Wi-Fi provides access to all mixer functions. Requires iOS 6 or higher. |
| Wi-Fi (both models) | USB Wi-Fi adapter included |
| Dimensions (HWD) | 56 mm x 333 mm x 245 mm
2.2” x 13.1” x 9.6” | 58 mm x 360 mm x 291 mm
2.3” x 14.2” x 11.5” |
| Weight | 4.3 lb (1.95 kg) | 5.9 lb (2.98 kg) |
| Power (both models) | 100–240 VAC, 50–60 Hz |
| Sampling Frequency (both models) | Selectable 44.1 kHz or 48 kHz |
| Internal Processing (both models) | 32-bit floating point |
| Frequency Response (both models) | 20 Hz–20 kHz ±0.5 dB, any input to any output |
| Dynamic Range (both models) | 105 dB |
| Equivalent Input Noise (both models) | -126 dBu |
| Residual Output Noise (both models) | -86 dBu |
| Crosstalk (both models) | -80 dB |
| S/N Ratio (both models) | -94 dB |
| Maximum Input Level (both models) | +16 dBu (Mic/Line inputs, XLR), +26 dBu (Mic/Line inputs, TRS), +22 dBu (Stereo inputs) |
| Phantom Power (both models) | 48V, individually switchable per channel |
| Included (both models) | USB WiFi adapter, soft carrying case, power supply |
