| Chassis Size | 381 mm (15") |
| Color | Black |
| Input Connections | Parallel Neutrik® NL4 |
| Speaker Type | Fullrange, Mid-High, Two-Way, Wedges |
| Frequency Response (-3 dB) | 60 - 20000 Hz |
| Frequency Response (-10 dB) | 42 - 20000 Hz |
| Internal Crossover | Yes |
| Recommended High-Pass Frequency | 42 Hz |
| Sensitivity 1 W/1 m | 100 dB |
| Max. SPL/1m (calc) | 132 dB |
| Coverage (Nominal -6 dB) H | 90 ° |
| Coverage (Nominal -6 dB) V | 50 ° |
| System Power Handling (Continuous/Program/Peak) | 400//1600 Watts |
| LF Transducer | 15-inch EVS15-SF |
| HF Transducer | 1.25-inch DH3/2010A |
| Crossover Frequency | 1500 Hz |
| Nominal Impedance (Passive) | 8 Ω |
| Minimum Impedance | 6.5 Ω |
| Enclosure Material | High Impact Polystyrene |
| Flying | Yes |
| Outdoor | No |
| Grill | Polyester Powder Coated, 18GA Galvanized Steel |
| Height | 686 mm (27.01") |
| Width | 445 mm (17.52") |
| Depth | 406 mm (15.98") |
| Weight Net | 20.2 kg (44.53 lbs) |
