| HDMI | HDMI 2.0 |
| HDCP | HDCP 2.2 @ ARC |
| Video Bandwidth | 6 Gbps/x3Channel (max) + Clock |
| Supported Resolutions & Distance | 480p, 720p, 1080i, 1080p, 3DFull HD 1920 x 1080, WUXGA 1920 x 1200, 2K, 4K(30p), 4K(60p) |
| O/E Converter | 4 channel 850 nm VCSEL array (Source) 4 CH GaAs PD array (Sink) |
| Connector Type | HDMI 2.0 type A |
| Cable Type | 4 core OM3 Multimode Fiber ( High Speed Data ) and 7 core Copper Cable |
| Jacket Outer Material | Black PVC jacket |
| Cable Weight | TBD |
| Cable Color | Black |
| Maximum Tension force | 100N |
| Minimum Bend Radium | 20mm |
| Differential Input | 100 ohm (typical) |
| Operating temperature | -40°C to 70°C |
| Power Consumption | 250mW (max) |
| Power Supply | No external power required |
| Compliants | RoHS 2.0 & REACH compliant |
| Package | Box |
