HDMI | HDMI 2.0 |
HDCP | HDCP 2.2 @ ARC |
Video Bandwidth | 6 Gbps/x3Channel (max) + Clock |
Supported Resolutions & Distance | 480p, 720p, 1080i, 1080p, 3DFull HD 1920 x 1080, WUXGA 1920 x 1200, 2K, 4K(30p), 4K(60p) |
O/E Converter | 4 channel 850 nm VCSEL array (Source) 4 CH GaAs PD array (Sink) |
Connector Type | HDMI 2.0 type A |
Cable Type | 4 core OM3 Multimode Fiber ( High Speed Data ) and 7 core Copper Cable |
Jacket Outer Material | Black PVC jacket |
Cable Weight | TBD |
Cable Color | Black |
Maximum Tension force | 100N |
Minimum Bend Radium | 20mm |
Differential Input | 100 ohm (typical) |
Operating temperature | -40°C to 70°C |
Power Consumption | 250mW (max) |
Power Supply | No external power required |
Compliants | RoHS 2.0 & REACH compliant |
Package | Box |
