The MKH 416 is a short gun interference tube microphone. Its excellent directivity and compact design, high consonant articulation and feedback rejection make the MKH 416 a superb all-round microphone for film, radio and television, especially
for outside broadcast applications.
Features
Increased directivity due to interference tube principle
Very low inherent self-noise
High sensitivity
Transformerless and fully floating balanced output
Rugged, suitable for adverse climatic conditions
Matt black all-metal body
Dimensions | Ø 19 x 250 mm |
---|
Frequency response (microphone) | 40.....20000 Hz |
---|
Transducer principle (Microphone) | RF condenser microphone |
---|
Pick-up pattern | super-cardioid/lobar |
---|
Sensitivity in free field, no load (1kHz) | 25 mV/Pa +- 1 dB |
---|
Nominal impedance | 25 Ohm |
---|
Min. terminating impedance | 800 Ohm |
---|
Equivalent noise level | 13 dB |
---|
Equivalent noise level weighted as per CCIR 468-3 | 24 dB |
---|
Maximum sound pressure level (passiv) | 130 dB |
---|
Current consumption | 2 mA |
---|
Voltage | 48 +- 4 V Phantom |
---|
What s in the box?
- 1 MKH 416 P 48 U 3
- 1 MZW 415 windshield
- 1 MZQ 100 microphone clamp
