Compact in stature but big on output, the white EUROCOM Ultra Compact 200W 2-Way 4Ω Loudspeaker System from Behringer delivers an impressive sonic performance. This professional 2-way loudspeaker system is suitable for a wide variety of fixed installation applications. Featuring clean lines and a unique fabric-finished wrap-around grille, the speaker system is fully at home in even the most elegant settings, including theaters and auditoria, places of worship, themed entertainment, and sporting venues. Although designed for serving as mains in small rooms, the CL206W Loudspeaker system can also be used for fill and delay systems in larger rooms.
Built from quality laminated Baltic birch plywood, the CL206W s lightweight cabinet combines natural rigidity and acoustic inertness with the additional strength of internal steel bracing. Threaded mounting-point inserts in the internal brackets provide a rated load factor of at least 10 times the overall cabinet weight, making this system safe for flown installation, either single or in arrays. The system also achieves fully-professional performance and reliability with its custom-tailored components for frequency response, sensitivity, and power handling.
The system employs dual 6" (152.4mm) low-frequency drivers providing full, rich lows, matched to a 1" (25.4mm) high-frequency driver via an internal passive crossover at 2 kHz, to deliver clear, smooth sound across the entire audible spectrum. A rotatable waveguide allows optimal application of the 90 x 70° coverage pattern, regardless of speaker orientation, which may be either vertical or horizontal.
Every aspect of the CL206W speaker system has been thought through to maximize value and convenience for both the installer and the end user. The result is an attractive, durable, installation-ready loudspeaker system that will deliver top-notch sound for years to come. In addition, the refined aesthetic design compliments your sophisticated interior spaces. This loudspeaker system is trapezoidal in shape with rotatable high frequency sections for deployment in both vertical and horizontal orientations.
Frequency Range | 57 Hz to 20 kHz (-10 dB) |
Frequency Response | 64 Hz to 15 kHz (+/-3 dB) |
Dispersion | Nominal Horn Waveguide: 90 x 70º (H x V), rotatable |
Directivity | Factor (Q): 7.5 Index (DI): 8.8 dB |
Sensitivity | 1 W at 3.2 (1 m) Passive: 90 dB (half space) |
Crossover | Modes: Passive |
Crossover Frequency | 2 kHz |
Power Handling | 200 W RMS at 28.3 V (long term, IEC passive) |
Nominal Impedance | 4 Ω |
Low Frequency Driver | 2 x 6" (152.4 mm) at 120 W |
High Frequency Driver | 1" (25.4 mm) at 20 W |
SPL | Maximum Continuous: 113 dB SPL (passive) Maximum Peak: 119 dB SPL (passive) |
Overload Protection | Full range power limiting to protect drivers and crossovers |
Enclosure | Trapezoidal 15° side angle, laminated birch plywood |
Grille | Steel |
Rigging Points | 14 x M6 threaded points 4 x M6 threaded inserts for OmniMount 30 series |
Termination | NL4 and 4-position terminal strip |
Dimensions (H x W x D) | 25.0 x 10.2 x 11.7" (635.0 x 259.0 x 297.1 mm) |
Weight | 29.5 lb (13.3 kg) |
