- 80 W continuous program power capacity
- 1" horn throat diameter
- 44 mm (1.7 in) aluminium voice coil
- Mylar diaphragm
- 1500 - 18000 Hz response
- 107 dB sensitivity
Throat diameter
25 mm (1.0 in)
Nominal impedance
8 Ω
Minimum impedance
7.4 Ω
Nominal power handling *
40 W
Continuous power handling *
80 W
Sensitivity (1W/1m) *
107.0 dB
Frequency range
2 - 18 kHz
Recommended crossover *
2.0 kHz
Voice coil diameter
44 mm (1.7 in)
Winding material
Aluminium
Inductance
0.11 mH
Diaphragm material
Mylar
Flux density
1.5 T
Magnet material
Ceramic
