Diversity Receiver ile ULX2 SM58 Verici Mikrofonu ile komple set, Aynı anda problemsiz çalışabilir Mikrofon Sayısı : 24Gruplandıralabilir otomatik Frekans seçimi 1400 adet seçilebilir frekans Diversity 5-segment transmitter audio sinyal göstergesi 5-segment RF göstergesi 3-segment transmitter batarya durum göstergesi multi-fonksiyonlu LCD grup kanal göstergesi Mic/Line anahtarlı, Remotable 1/2-wave anten Frekans ve volume kilitleme XLR ve 1/4-inch output Metal kasa 1/2 rack ölçüsünde RF Frekans Taşıma aralığı 554.000 -865.000 Mhz. 100 mt. çekim mesafesi Audio Frekans cevabı 25 Hz-15 kHz1/4 inch connector (into 3000 ohm load): –2 dBV Impedance: ULXP4 (output): 50 ohms at line level; 2000 ohms at mic level Modulation: ± 38 kHz deviation compressor-expander system with pre- and de-emphasis. RF Power Output: 30 mW maximum Dynamic Range: >100 dB, A-weighted RF Sensitivity: 1.26 uV for 12 dB SINAD (typical) Image Rejection: 80 dB typical Spurious Rejection: 75 dB typical Ultimate Quieting (reference ± 38 kHz deviation): >105 dB, A-weighted System Distortion (reference ± 38 kHz deviation, 1 kHz modulation): 0.3% total harmonic distortion, typical Power Requirements: 9V alkaline battery; 8.4 V Nicad optional; Receiver 14 - 18 Vdc (negative ground), 550 mA Battery Life: 8 to 9 hours (with 9V alkaline battery) Vocal Mikrofon Özellikleri ;Type: Dynamic (moving coil) Frequency Response: 50 to 15,000 Hz Polar Pattern: Unidirectional (cardioid), rotationally symmetrical about microphone axis, uniform with frequency Sensitivity (at 1,000 Hz Open Circuit Voltage): -54.5 dBV/Pa (1.85 mV) 1 Pa = 94 dB SPL Impedance: Rated impedance is 150 ohms (300 ohms actual) for connection to microphone inputs rated low impedance Polarity: Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3 Connector: Three-pin professional audio connector (male XLR type)
