For applications requiring a higher level of sophistication and capability, the MA6000M 8 Mic/Line auto-mixer will set a new standard for integrated mixer-amplifiers. The extensive feature set includes eight universal inputs with individual two-band equalization, direct outputs and adaptive proportional gain automatic mixing for use in speech reinforcement systems that can be expanded to accommodate up to 32 inputs. In addition, four auxiliary inputs are provided with intuitive front panel selectors to allow users to quickly and easily select between music sources. Equipped with remote volume control, source selection and system power, the MA6000M auto-mixer is aimed at installations in conference centers, council chambers, courtrooms, hotel meeting rooms and many other venues.
The MA6000M auto-mixer combines a fresh and modern aesthetic design with innovative technologies which will set new standards in distributed system designs. With a focus on sustainability, the MA6000M product family employs high efficiency electronics, resulting in significantly lower power consumption and operating costs. Aimed at enabling LEED certified applications they also create a vastly smaller carbon footprint than conventional products built around legacy technologies.
| Audio Inputs | 8x Combo XLR/TRS mic/line 8x 5-Pin Euroblock mic/line (in parallel) 1x 5-Pin Euroblock bridge input 4x Stereo summed RCA auxiliary 1x 4-Pin Euroblock page input |
| Input Impedance | Mic: -50 to 0 dBV @ 600 Ω (electronically balanced) Line: -27 to 0 dBV @ 600 Ω (electronically balanced) Auxiliary : -10 dBV @ 10 kΩ (unbalanced) |
| Preamp Output | 70 V Input: 1x 5-Pin Euroblock Impedance: 0 dBV @ 600 Ω (balanced) 4 Ω Input: 1x 5-Pin Euroblock Impedance: 0 dBV @ 600 Ω (balanced) Hi-Z & Lo-Z Preamp Output: 2x 5-Pin Euroblock Impedance: 0 dBV @ 600 Ω (balanced) |
| Phantom Power | 24 VDC Switchable on inputs 1 to 8 and Tel/Page input |
| Audio Outputs | 1x 3-Pin male Euroblock main mix output (mic/line switchable) 8x 5-Pin Euroblock direct outs 1x 5-Pin Euroblock bridge out 1x 5-Pin Euroblock zone 2/MOH out |
| Output Impedance | Mic: -36 dBV @ 1 kΩ Line: 4 dBV @ 600 Ω Direct Out: 0 dBV @ 600 Ω (balanced) Zone 2: 4 dBV @ 600 Ω (balanced) MOH: 0 dBV @ 600 Ω (balanced) |
| Dynamic Range | Mic: 65 dB Line: 80 dB |
| THD & Noise | 0.5% @ 1 kHz (rated output) |
| Frequency Response | 50 Hz to 18 kHz (± 2 dB) |
| Tone Controls | Master: Low: ± 10 dB @ 100 Hz High: ± 10 dB @ 12 kHz Inputs 1 to 8: Low: ± 15 dB @ 100 Hz High: ± 15 dB @ 12 kHz |
| Connections | Remote: 1x 5-Pin Euroblock Common: -5 VDC @ 100 mA (short-circuit protected) Remote Power: 5 VDC @ 100 mA (current limited, short-circuit protected) RVC: 10 kΩ linear taper potentiometer Aux Input Select: used in conjunction with wall remote to select aux feed Power On/Off: 5 VDC voltage make contact input, no open voltage Inputs 1 to 8: no voltage make contact input; open voltage 5 VDC, short circuit < 10 mA |
| Indicators | Power: Yellow LED ring illumination Overload: Red LED ring illumination Output Level: LED VU meter (yellow and red when clipping) |
| Power Supply | Mains Voltage: 100 to 120/220 to 240 VAC, 60/50 Hz (switchable) Power Consumption: 26 W Fuse: T 1 AH 250 V Mains Connector: Standard IEC Receptacle |
| Dimensions (H x W x D) | 3.5 x 17.0 x 16.0" (8.8 x 43.2 x 40.6 cm) |
| Weight | 11 lb (5 kg) |
