Crown XLI800 Power Amplifier
The Crown XLi800 Power Amplifier offers affordable live sound amplification that is powerful, rugged and reliable. Built for musicians, DJs, and entertainers as well as houses of worship, discos, and pubs; the XLi800 features 300 Watts of power, RCA and XLR inputs, selectable input sensitivity of 0.755V or 1.4V, Speakon and binding post outputs, stereo/parallel/bridge-mono mode, power/fault/signal presence/clip indicators, forced-air cooling; and protection against shorts, no-load, on/off thumps and radio-frequency interference.
Crown XLi800 Power Amplifier Features
- 300 Watts per Channel at 4 Ohms
- Stereo/parallel/bridge-mono mode
- User selectable input sensitivity - 0.775V and 1.4V
- Electronically balanced RCA and XLR inputs; binding post and Speakon outputs
- Efficient forced-air cooling prevents excessive thermal buildup
- Electronically balanced RCA and XLR inputs; binding post and Speakon outputs
- Two level controls, power switch, power LED, and six LEDs which indicate signal presence, clip and fault for each channel
- Protection against shorts, no-load, on/off thumps and radio-frequency interference
With over six decades of experience designing and building rock-solid products, Crown is the standard in amplifier technology. So check out the affordable Crown XLI Series. They are a powerful argument for quality and value!
The four models in the series are the XLi800, XLi1500, XLi2500 and XLi-3500. They are identical except for output power.
Crown XLi800 Power Amplifier Specifications
- Channels: 2
- Guaranteed Minimum Power:
- 4 ohm stereo (per channel): 300 watts
- 8 ohm stereo (per channel): 200 watts
- 8 ohm bridge mono: 600 watts
- Sensitivity (full rated power at 8 ohms): 0.775V or 1.4V
- Signal to Noise Ratio (below rated power 20Hz to 20kHz, A-Weighted): > 100 dB
- Total Harmonic Distortion (THD) (20Hz - 20kHz): < 0.5%
- Inter Modulation Distortion (60Hz and 7kHz at 4:1 from full rated output to -40 dB): = / < 0.35%
- Frequency Response (at 1W, 20Hz - 20kHz): 0 dB, -1 dB
- Crosstalk (below rated power):
- at 1kHz: -75 dB
- at 20kHz: - 59 dB
- Damping Factor (from 10Hz to 400Hz, 8 ohms): > 200
- AC Line Voltage and Frequency Configurations (± 10%):
- 120VAC 60Hz
- 220VAC 50/60Hz
- 230-240VAC 50/60Hz
- Dimensions (H x W x D): 3.5 x 19 x 12.4 inches (89 x 482 x 315mm)
- Weight: 25.1 lb (11.4 kg)
