DBX DI4 Aktif 4 Kanallı DiBox
TEKNİK ÖZELLİKLER
| Audio Input Connectors | 1/4" TS unbalanced |
| Input Impedance | 320k Ohms |
| Peak Input Level | +15 dBu |
| Headphone Connector | 1/4" Jack |
| Stereo Line Mixer Outputs | RCA Connectors |
| XLR Balanced Outputs | XLR Connectors |
| Output Impedance | 600 Ohms |
| Max Output Level | +16 dBu |
| Frequency Response | 20 Hz–20 kHz, 0 dB to -2 dB |
| THD+Noise | 0.0008% typical at +4dBu, 1 kHz |
| Interchannel Crosstalk | <-90dB, 20 Hz–20 kHz |
| Power Supply | ~ 100-120 V AC, ~ 200-240 V AC, 50-60 Hz |
| Power Consumption | 775 mW |
| Dimensions | 1 3/4“ (44.5 mm) x 8“ (230.6 mm) x 8 1/2“ (217 mm) |
| Weight | Net weight approx. 3.85 lbs. (1.75 kg) |
