Enorm CS506EN EN54-24 Certified Surface Mount 5" Ceiling Speaker
CS506 EN is a versatile 5" 100V ceiling speaker for general use. You can make general announcements, background music, and emergency announcements in buildings such as schools, factories, shopping centers, stations, airports, etc., in accordance with the EN54-24 standards. Its water and dust resistance is rated at IP 21.
The 5" full-range speaker features a 100V multi-tap transformer, ceramic speaker line connector, and thermal fuse. The high-quality 100V multi-tap transformer of the speaker has power options of 3W-6W. This allows the announcement broadcast on the speaker line to continue in case of any malfunction in the speaker. Our easy installation design helps users to easily mount the speaker to the ceiling. The exterior of the speaker cabinet is made of flame-retardant white ABS plastic, and the front panel is made of steel. The CS506 is equipped with a fire dome to prevent the spread of fire or smoke from the ceiling cavity in case of a fire and can be mounted on the speaker without the need for additional equipment.
- Rated Power: 6W (100V)
- Transformer Power Levels: 3 - 6W
- Impedance: 3330Ω (3W) - 1665Ω (6W)
- Speaker System: Full Range
- Measurement Environment: Free-Field
- Main Material: ABS Plastic & Steel EN60695*An 1,2
- Measurements: 173x135x100 mm
- Color: White
- Weight: 620 gr
- Enclosure: IP21 Type A
- ABS Plastic Enclosure: IEC 60695-11-10 / UL94
