FBT Ventis-112A 12" Aktif Hoparlör, Bi-Amp, 1800W
- 2-way, bi-amplified, bass reflex design
- Biamped: 700W RMS LF and 200W RMS HF power amplifiers in Class D for LF and in Class H/AB for HF
- Digital Signal Processor with graphic display
- 15 mm (0.59”) birch plywood scratch resistant enclosure and internal bracing
- High efficiency switch mode power supply
- Control Panel features balanced XLR/Jack input, XLR LINK OUT, 2 x Volume, RCA Stereo input, DSP display with rotative encoder and push
- 320mm (12”) LF woofer with 64mm (2.5”) voice coil, custom made for FBT
- 25mm (1”) exit throat B&C HF compression driver with 36mm (1.4”) voice coil
- Frequency response from 48Hz to 20 kHz
- 80°H x 50°V Constant Directivity Rotatable Horn
- 6 x M10 suspension points, optional wall bracket mount thread, 35mm (1 3/8”) top-hat
- Speaker stand socket, two aluminium handles
- 45° monitor tape
Technicial Specifications
| Configuration: | 2 way |
| Built-in amplifier LF/HF: | 700/200 W RMS |
| Built-in amplifier peak LF/HF: | 1400/400 W |
| Frequency response: | 42Hz - 20KHz -6dB |
| Low Frequency woofer: | 12 - 2.5 coil inch |
| High Frequency driver: | 1 - 1.4 coil inch |
| Maximum SPL cont/peak: | 126/133 dB |
| Dispersion: | 80° x 50° rotatable HxV |
| Input impedance: | 22 Kohm |
| AC Power requirements: | 640 VA |
| Input connector: | XLR with loop, RCA ST |
| Power cord: | 5/16.4 m/ft |
| Net Dimension (WxHxD): | 387x665x380 / 12.23x26.18x14.96 mm/inch |
| Net Weight: | 20.6/45.41 Kg/lb |
| Transport Dimension (WxHxD): | 500x765x470 / 19.68x30.11x18.50 mm/inch |
| Transport Weight: | 23.1/50.92 Kg/lb |
