Versatile 16-Input Configuration Adapts to Varied Source Requirements
The EMX5016CF has a total of 16 input channels - eight for monaural microphone or line input plus four stereo pairs. The stereo channel pairs can function either as monaural microphone inputs or stereo line inputs. This system gives you extra microphone inputs if your sources are mostly microphones, or if you need to handle more stereo sources the EMX5016CF will comfortably handle four pairs in addition to eight monaural microphone or line inputs. Switchable phantom power is provided for all microphone inputs.
Advanced Channel EQ
3-band EQ is available on all input channels, but extra versatility is provided on the eight mono channels with mid-frequency sweep controls. The mid EQ center frequency can be continuously swept from 250 Hz through 5 kHz so you can precisely pinpoint frequencies in the critical midrange that require compensation, providing significantly enhanced equalization potential
| Maximum output power | 500W + 500W (4ohms), 370W + 370W (8ohms/ AC100V model) 350W + 350W (8ohms/ AC120V model) 320W + 320W (8ohms/ AC220-240V model) @1kHz, THD+N ≤ 0.5% | |
| Total harmonic distortion (THD+N) @ 20-20kHz | Less than 0.3%, +14dBu output into 600ohms | |
| Frequency response GAIN=Minimum, PAD=OFF | 0, +0, -3dB, 20Hz-20kHz, 0dB @1kHz | |
| Equivalent input noise GAIN=Maximum, 20-20kHz | -128dBu | |
| Crosstalk @ 1kHz | -68dB, adjacent inputs | |
| -68dB, input to output | ||
| Phantom voltage | +48V | |
| Channel equalizer +15,-15dB Maximum | HIGH: 10kHz (Shelving) | |
| MID(MONO): 250Hz-5kHz (Peaking) | ||
| MID(ST) 2.5kHz (Peaking) | ||
| LOW: 100Hz (Shelving) | ||
| Compressor (COMP) | On each channel; One control adjusts the Gain, threshold and Ratio simultaneously | |
| Channel peak indicator | LED turns on when post EQ signal reaches -3dB below clipping | |
| Channel signal indicator | LED turns on when post EQ signal reaches -10dB | |
| Feedback suppressor | AUTO/MANUAL mode | |
| LED level meter (ST, PFL/AFL) | 2*12 points LED meter (PEAK,+5,+3,+1,0,-1,-3,-5,-7,-10,-15,-20 dB) PEAK lights if the signal comes within 3 dB of the clipping level. | |
| Frequency response correction system | Pink noise/Music playback measurement mode | |
| Maximizer | 3-band compressor ON/OFF | |
| Digital graphic equalizer | 9-band, ±12dB; Preset x3, User preset x3 | |
| Digital effect | 16 programs, Parameter control Foot switch (FC5:Option) for Effect ON/OFF | |
| Lamp | XLR-3-31 type, 12V DC between pins 2 and 3, 5W max. | |
| Power amplifier protection | POWER switch on/off mute DC-fault Thermal / heatsink temp ≥ 90 degrees celsius Vl limiter / RL≤2 ohms Clip limiter / THD≥1%, Indicator x 2 | |
| Power supply protection | Thermal / heatsink temp ≥ 100 degrees celsius | |
| Cooling | Variable-speed fan ( x 2) | |
| Power consumption | Japan: | AC100V 50/60Hz, 500W |
| North America: | AC120V, 60Hz, 500W | |
| Other Areas: | AC220-240V, 50/60Hz, 500W | |
| Dimensions (W x H x D) | 444 x 155 x 493 mm / 17.48 x 6.1 x 19.41 in | |
| Weight | 11kg / 24.25lbs | |
| Input terminal | PAD | GAIN | Actual load impedance | For use with nominal | Input level | Connector | ||
|---|---|---|---|---|---|---|---|---|
| Sensitivity | Nominal | Max. before clip | ||||||
| CH INPUT A 1-8 | 0dB | -60dB | 3kohms | 50-600 ohm Mics | -80dBu | -60dBu | -40dBu | XLR-3-31 type *3 |
| -16dB | -36dBu | -16dBu | +4dBu | |||||
| 26dB | -34dB | -54dBu | -34dBu | -14dBu | ||||
| +10dB | -10dBu | +10dBu | +30dBu | |||||
| CH INPUT B 1-8 | 0dB | -60dB | 10kohms | 600ohm Lines | -80dBu | -60dBu | -40dBu | TRS phone jack |
| -16dB | -36dBu | -16dBu | +4dBu | |||||
| 26dB | -34dB | -54dBu | -34dBu | -14dBu | ||||
| +10dB | -10dBu | +10dBu | +30dBu | |||||
| ST CH MIC INPUT 9/10-15/16 | -60dB | 3kohms | 50-600 ohm Mics | -80dBu | -60dBu | -40dBu | XLR-3-31 type | |
| -16dB | -36dBu | -16dBu | -10dBu | |||||
| ST CH LINE INPUT 9/10-15/16 | -34dB | 10kohms | 600ohm Lines | -54dBu | -34dBu | -14dBu | Phone jack, RCA pin jack | |
| +10dB | -10dBu | +10dBu | +30dBu | |||||
| CH INSERT IN (1-8) | - | 10kohms | 600ohm Lines | -20dBu | 0dBu | +20dBu | Phone jack | |
* 0dBu= 0.775Vrms
| Output terminal | Actual source impedance | For use with nominal | Output level | Connector | |
|---|---|---|---|---|---|
| Nominal | Max. before clip | ||||
| ST OUT [L,R] | 150ohms | 600ohm Lines | +4dBu | +20dBu | TRS phone jack |
| ST SUB OUT [L,R] | 150ohms | 600ohm Lines | +4dBu | +20dBu | TRS phone jack |
| AUX SEND 1,2 | 150ohms | 600ohm Lines | +4dBu | +20dBu | TRS phone jack |
| EFFECT SEND 1,2 | 150ohms | 600ohm Lines | +4dBu | +20dBu | TRS phone jack |
| CH INSERT OUT 1-8 | 600ohms | 10kohm Lines | 0dBu | +20dBu | TRS phone jack |
| REC OUT [L,R] | 600ohms | 10kohm Lines | -10dBV | +10dBV | RCA pin jack |
| PHONES [L,R] | 100ohms | 40ohm Lines | 3mW | 75mW | ST phone jack |
| SPEAKERS | 0.1ohms | 4ohm Speakers | 125W | 500W | SPEAKON Phone jack |
* 0dBu=0.775Vrms. 0dBV =1.0Vrms
