The Mikafon DP500 is a D-class power amplifier with a built-in DSP and matrix feature. It has a user-friendly interface that can be connected via TCP-IP. Unlike other devices in the market, it allows adjustment of output voltages for each channel. This feature provides a wide range of applications such as cafes, clubs, airports, stadiums, and public areas.
The DP series, consisting of DP200, DP500, and DP1000 devices, operate on the same principle. This user manual is divided into two classes as DP200 and DP500&DP1000.
General Features
- DSP
- Matrix
- D-class
- Sound adjustment for each channel
- Stereo bridge mode
- Easy-to-use MAS interface
Technical Specifications
- Frequency Response: ±0.1dB, 4Ω @20Hz-20kHz
- Total Harmonic Distortion: 0.05% @20Hz-20kHz
- Signal-to-Noise Ratio: >15V/μs
- External Input: Ethernet 1/10-100 Mb
- Input Sensitivity - Impedance: 20kΩ Balanced, 10kΩ Unbalanced
- Protections: Soft Start, Over Temp, Over Load, DC Out
- Dimensions (WxDxH):
- Without handle: 425x200x88 mm
- With handle: 480x200x88 mm
- Weight: 4 kg
- Output Power (Capacity) RMS 1kHz, 0.1% THD:
- Nominal: Stereo 2x300W or Bridge 1x600W
- Max Power: Stereo 2x500W or Bridge 1x1000W
- Additional Output/Voltage-Impedance:
- Mono: 2x 25V (2.7Ω),35V (5.4Ω),50V (11.1Ω),Bridge 1x 50V (5.5Ω),70V (10.8Ω),100V (22.2Ω)
