Neutrik NA-2I2O-DLINE is a Dante-Analog converter equipped with two analog inputs and two analog outputs. It can receive digital signals in AES/EBU format and integrate them into the Dante network. Its compact and portable design makes it suitable for stage, studio, or corporate audio systems. With its metal casing and high-quality XLR connectors, it is reliable and durable.
Neutrik NA-2I2O-DLINE is a Dante interface that allows for the conversion of analog and digital signals to the Dante network. This device enables easy routing of digital audio signals over the Dante protocol. Below are the description and technical specifications:
Technical Specifications:
- Conversion: Analog - Dante / Dante - Analog
- Inputs:
- 2 x XLR 3P analog input
- 2 x XLR 3P AES/EBU digital input (convertible)
- Outputs:
- 2 x XLR 3P analog output
- 2 x XLR 3P AES/EBU digital output
- Dante Protocol:
- 2 x Dante ports (EtherCON RJ45)
- Power Supply: Can operate with Power over Ethernet (PoE)
- Maximum Resolution: Audio resolution up to 24-bit / 96 kHz
- Noise Level: Lower than -90 dBu (Analog outputs)
- Output Level: Maximum +24 dBu
- Connection Interface: RJ45 EtherCON, locking XLR connectors
- Protection: Robust metal housing, resistant to tough conditions
- Dimensions: Compact, portable
- Weight: Approximately 0.6 kg
