M 4300 is a 400 W @ 4 Ohm 8 channel Class D professional audio amplifier, built in 1 rack unit metal enclosure. On the back, it has balanced signal inputs with XLR3 connectors and speaker outputs with Binding Post connectors, as well as stereo/bridge/parallel selectors. On the front panel we find the power switch, volume controls for each channel, and signal and limiter indicators.
Features
- Stereo / bridge / parallel mode.
- Front control of power and volume per channel.
- Limit, clip/signal indicator clip.
- 1 19-inch rack unit.
- Type Class D
- No. Chanels 4
- W/Ch @ 8 Ohm 300 W
- W/Ch @ 4 Ohm 400 W
- W Bridge @ 8 Ohm 600 W
- Frequency Range 20 Hz - 20 KHz
- Input Sensitvity 1 V
- THD+N <0.1 %
- S/N Rate >100 dB
- Damping Factor > 200
- Slew Rate 20 V/uS
- Connections Power: 1 x IEC, Audio In: 4 x XLR3, 4 x Audio Out Amp. XLN4
- Protections Soft start, DC, VHF, AC, Short circuit, Limiter, Temperature
