Control and others Reverb foot switch, STAGEPAS Controller (iOS/Android app)
On-board processors DSP SPX digital reverb (4 program, parameter control)
Powered subwoofer: Bass-reflex type, Line array speaker: Enclosed
Frequency range (-10dB) 37 Hz - 20 kHz
Coverage area H170ﾟ x V30ﾟ
Crossover 240 Hz
Maximum output level (1m; on axis) 125 dB SPL
Components LF Powered subwoofer: 12” (30 cm) Cone
HF Line array speaker: 1.5” (3.8 cm) Cone x 10
Amplifier class Class-D
Power rating Dynamic 1100 W
Power consumption 25 W (Idle),91 W (1/8 power)
Power requirements Depending on area of purchase: 100 V 50 Hz/60 Hz, 110-120 V 60 Hz, 220 V-240 V 50 Hz/60 Hz
Handle Top of powered subwoofer x1
Dimensions (W x H x D) System: 334 x 2,000 x 418 mm (maximum),Line array speaker: 67 x 582 x 86 mm, Powered subwoofer: 334 x 550 x 418 mm, Spacer: 67 x 555 x 86 mm (each)
Weight System: 23.0 kg (maximum),Line array speaker: 1.8 kg, Powered subwoofer: 20.0 kg, Spacer: 0.6 kg (each)
Accessories Power cord x 1, Cover x 1
Options Yamaha DL-SP1K (Dedicated dolly),FC5 (foot switch for reverb ON/OFF)
