JBL GSF3-GN, yeşil renkli dış mekan hoparlörü, özellikle alışveriş merkezleri, parklar, spor alanları gibi geniş alanlarda kullanım için tasarlanmış yüksek kaliteli bir arazi hoparlörüdür. 3 inçlik iki yollu koaksiyel yapıdadır.
Teknik özellikleri ;
| Frequency Range (-10dB) | 74 Hz – 20 kHz |
| Frequency Response (+/-3 dB) | 120 Hz – 15 kHz |
| Power Rating | 60 W Continuous Program (2 hrs) 30 W (120 W Peak),Continuous Pink Noise (2 hrs) 20 W (80 W Peak),Continuous Pink Noise (100 hrs) |
| Sensitivity | 84 dB (43 Hz - 110 Hz) |
| Maximum SPL | 103 dB peak (95 dB continuous, 2 hr) @ 1m |
| Coverage Pattern | 90° conical |
| Nominal Impedance | 8 Ω (at 8Ω tap) |
| Transformer Taps | 70V: 15 W, 7.5 W, 3.75 W 100V: 15 W, 7.5 W |
| Drivers |
|
| Terminals | Bare wire with dielectric-gel-filled wire nuts (1 meter single jacked cable 2 wires with 18 AWG) |
| Enclosure Material | Polycarbonate + ABS, UL94V-0 flammability rated |
| Color | Pine Green RAL 6028, or Beige Grey RAL 7006 |
| Dimensions | Cabinet 132 mm diameter x 167 mm deep (5.2 x 6.6 in). Assembly height 289 mm (11.4 in) with L-bracket base (at 90°) and 430 (17.0 in) with ground stake base |
| Net Weight | 1.7 kg (3.8 lbs) |
| Included Accessories | (1) Ground Stake Bracket; (1) L-Bracket |
| Directivity Factor (Q) | 7.9 |
| Directivity Index (dB) | 9 dB |
