The VIPER NT can be controlled via DMX 512. The connection is done with 5pin-XLR-plugs.
The DMX start address can be adjusted and saved via the control panel.
The machine can also be controlled with analog (0 - 10 V) via a lighting desk or via XLR-remote (option). This connection is done with 3pin-XLR-plugs.
A stand-alone-mode is also possible. The adjustments are done directly at the machine. A short press at the start button makes the machine run. Therefore a permanent pressing of the start button is unnecessary.
With the internal timer the fog time can be exactly adjusted in seconds, the wait time in minutes and the output in %.
The control panel with LED-display, simple symbols allow for easy operation. It also protects the control buttons against dirt.
Digital technology makes fine adjustment of the pump possible. In steps of 1% the output can be adjusted from 0 - 99%. Thus, any desired effect from a tiny fog-cloud to the thickest fog can be produced. This enables the viper nt to be used in both small and large locations.
Procedure | Vaporizing fog generator |
Power requirement | 1300 Watt |
Voltage | 230 V / 50 Hz 120 V / 60 Hz |
Warm up time | approx. 7 min. |
Fluid consumption | 120 ml/min. . 35 ml/min. |
Fluid tank capacity | 5 Liter |
Fog output | adjustable in 99 steps |
Output projection | max. 15 m |
| Fogging time at max. output at < 50% output |
|
Control | DMX 512 |
| Temperature control | Microprocessor controlled |
| Overheating protection | Heater block/Thermostat |
Dimensions (L x W x H) | 47 x 23 x 24 cm |
Weight without bottle | approx. 8,3 kg |
Description of the accessories see accessories-site.
The following Look-fluids are available for the VIPER NT:
