WOX SUH4E-H2 1:4 HDMI Çoklayıcı, 4K@60

mağazada STOK YOK. teklif isteyin. 1-3 günde teslim edebiliriz
Hızlı Gönderi
  • Supports HDMI 2.0 and the video resolution up to 4K@60Hz 4:4:4.
  • HDMI input supports HDCP 2.3 and the outputs support HDCP Active or HDCP Passive mode.
  • Supports video resolution down-scaling, the 4K input can be automatically degraded to 1080p output for compatibility with 1080p display.
  • 18Gbps high bandwidth.
  • Advanced EDID management: multiple built-in EDID settings can be selected.
  • Built-in equalizer for signal enhancement to avoid signal attenuation in transmission.
  • Supports CEC pass-through.
  • Provides LEDs to indicate the current operating status.
  • Firmware upgrade by Micro-USB port.

Technicial Specifications

Video Input
Input(1) HDMI
Input Connector(1) Type-A female HDMI
HDMI Input ResolutionUp to 4Kx2K@60Hz 4:4:4 8bit
HDMI Standard2.0
HDCP Version2.3, 1.4 compliant
CECSupported
Video Output
Output(4) HDMI
Output Connector(4) Type-A female HDMI
HDMI Output ResolutionUp to 4Kx2K@60Hz 4:4:4 8bit
HDMI Standard2.0
HDCP Version2.3, 1.4 compliant
CECSupported
Control
Control Part(1) EDID 4-pin DIP switch, (1) Micro-USB port
General
Bandwidth18Gbps
HDMI 2.0 Cable Length4K@60Hz 4:4:4 ≤ 5m, 4K@60Hz 4:2:0 ≤ 15m,
1080p ≤ 20m
Operation Temperature-10℃ ~ +55℃
Storage Temperature-25℃ ~ +70℃
Relative Humility10%-90%
Power SupplyInput:100V~240V AC, Output: 5V DC 1A
Power Consumption2.5W (Max)
Dimension (W*H*D)142.0mm x 17.6mm x 70.4mm
Net Weight260g

Note: Please adopt high-qualified HDMI cable fully compliant with HDMI 2.0 for reliable transmission and connection.
